What’s This For?

• Epiphone Guitars using the “Inspired By Gibson Custom” bridge system
• Not for the single-cut IGC Les Paul Custom. That guitar uses large bushing mounted bridge posts, so it takes E-Sert or ESWKIT, not IBG-Sert
• Easy installation! (See video, below)
• Works with Faber® ABRM, or Faber® Tone-Lock™ Bridge
• Be sure to measure the depth of the bridge stud hole prior to installation of the IBG-Sert™
• View installation video, Applicable to Insert™, E-Sert™, IBG-Sert™ and USA/ABR-1 “Plus” post Installations



• SPECIFICATIONS:
• Material: Studs, German Bell Brass, plated; Thumbwheels, Brass, plated
• Weight, with thumbwheels: .885 oz./25.1g
• Overall length: 1.25” / 31.75mm
• Length below flange: .55” / 14.0mm
• Stud length, above flange: .59” / 15.0mm
• Diameter, lower section: .296” / 7.52mm
• Fluted section below flange: .322″/8.18mm
• Flange diameter: .393” / 10mm
• Flange thickness: .061” / 1.55mm
• Thumbwheels: Diameter – .63″/16mm; Thickness – .11″/2.8mm
